Elation Professional - www.elationlighting.com - ELED TW Strip Instruction Manual Page 13
Elation Professional - www.elationlighting.com - ELED TW Strip Instruction Manual Page 14
Channel 1, 2, & 3 will not work, when Channel 4 is being used.
When using Channel 6, Channel 5 will control the speed of the
color changing.
ELED TW Strip 7 Channel Mode
Channel Value Function
1 COOL WHITE
0 - 255 0% - 100%
2 WARM WHITE
0 - 255 0% - 100%
3 AMBER
0 - 255 0% - 100%
4 0 - 255 COLOR MACROS
PLEASE SEE COLOR MACRO CHART ON PAGE 16
5 STROBING/PROGRAM SPEED
0 - 15 NOTHING
16 - 255 STROBING
SLOW - FAST
0 - 255 PROGRAM SPEED SLOW - FAST
6 MODE
0 - 127 OFF
128 - 159 AUTO MIX
160 - 191 3 COLOR JUMP
192 - 223 7 COLOR JUMP
224 - 255 SOUND ACTIVE
7 0 - 255 MASTER DIMMER 0% - 100%
ELED TW Strip 27 Channel Mode
Channel Value Function
1 COOL WHITE (LED 1 & 2)
0 - 255 0% - 100%
2 WARM WHITE (LED 1 & 2)
0 - 255 0% - 100%
3 AMBER (LED 1 & 2)
0 - 255 0% - 100%
4 COOL WHITE (LED 3 & 4)
0 - 255 0% - 100%
5 WARM WHITE (LED 3 & 4)
0 - 255 0% - 100%
6 AMBER (LED 3 & 4)
0 - 255 0% - 100%
7 COOL WHITE (LED 5 & 6)
0 - 255 0% - 100%
8 WARM WHITE (LED 5 & 6)
0 - 255 0% - 100%
*CHANNELS 9-19 THE SAME WARM WHITE, COOL WHITE, AMBER LED PATTERN CONTINUES*
*THE DIRECTION IN WHICH THE PIXELS LIGHT UP CAN BE SWITCHED USING THE DIRECTION SET FEATURE ON PAGE 8*
20 WARM WHITE (LED 13 & 14)
0 - 255 0% - 100%
21 AMBER (LED 13 & 14)
0 - 255 0% - 100%
22 COOL WHITE (LED 15 & 16)
0 - 255 0% - 100%
23 WARM WHITE (LED 15 & 16)
0 - 255 0% - 100%
24 AMBER (LED 15 & 16)
0 - 255 0% - 100%
25 COOL WHITE (LED 17 & 18)
0 - 255 0% - 100%
26 WARM WHITE (LED 17 & 18)
0 - 255 0% - 100%
27 AMBER (LED 17 & 18)
0 - 255 0% - 100%
