LED Display Backlight On/Off:

To set the LED display to turn off after 10 seconds, press the MODE

button until “Disperm BackLight” is displayed. Either “On” or “Off” will

be displayed. Press the UP or DOWN button so that “Off” is displayed,

the display will now turn off after 10secs. Press any button for at least

5secs. to turn the display on again. Be advised though that the display

will turn off automatically after 10 seconds of inactivity. To make the

backlight display stay on at all times, press the UP of DOWN button so

that “On” is displayed.

Operating Modes:

You can use the ELED TW Strip in four ways:

• Macro Mode - There are 35 color macros to choose from.

• Program Mode - There are 15 built in programs and sound active

mode to choose from.

• Fade Mode - This mode is used in conjunction with the Macro mode.

• WW/CW/AM mode - Control the intensity of all 3 colors adjusting the

intensity to your desire.

• DMX control mode - This function will allow you to control each

individual fixtures traits with a standard DMX 512 controller such as

as the Elation® Show Designer™.

Macro Mode:

1. Plug the fixture in and press the MODE button until “Color Macro” is

displayed.

2. There are 35 macros to choose from. Select your desired macro by

pressing the UP and DOWN buttons.

Fade Program: This mode is used in conjunction with the WW/CW/

AM mode.

1. To run a fade program first create your desired color in WW/CW/AM

mode. After you have created your color press the MODE button

until “Program Fade Speed” is displayed.

2. Press the UP or DOWN buttons to make the adjustmetns. “Speed 0”

is the slowest speed, “Speed 15” the fastest speed.

Program Mode:

1. Plug the fixture in and press the MODE button until “Color Program”

is displayed.

2. There are 15 built-in programs to choose from or you can select

“sound active” to run the unit by sound. Select your desired program

ELED TW Strip Operating Instructions

Elation Professional - www.elationlighting.com - ELED TW Strip Instruction Manual Page 8Elation Professional - www.elationlighting.com - ELED TW Strip Instruction Manual Page 7

by pressing the UP and DOWN buttons. You can set your program

speed by following the next set of instructions. The direction of cer-

tain programs can also be changed under Directions Set.

Direction Set: This feature is used in conjunction with 27 Channel

DMX mode and 54 Channel DMX Mode. The direction in which the pixels

light up can be reversed so that the pixel line up can start at either end

of the bar. This feature is useful when the unit is installed in a reversed

orientation so the unit itself does not have to be uninstalled and reversed.

Example: When using 27 Channel mode, Channel 1 LEDs 1 & 2 can

start at either end of the bar depending on the “Direction Set” set

up.

1. To adjust the speed of your program press the MODE button until

“Direction Set” is displayed.

2. Press the UP or DOWN buttons to select “Positive” in which the pix-

els light up from right to left, or “Negative” in which the pixels will

light up left to right.

Program Mode Speed Adjustment:

1. To adjust the speed of your program press the MODE button until

“Color Speed” is displayed.

2. Press the UP or DOWN buttons to make the adjustmetns. “Speed 1”

is the slowest speed, “Speed 16” the fastest speed.

WW/CW/AM Mode:

1. Plug the fixture in and press the MODE button until:

2. When “Single Color Cool White” is displayed you are in Cool White

dimming mode. Press the UP and DOWN buttons to adjust intensity.

3. When “Single Color Warm White” is displayed you are in Warm White

dimming mode. Press the UP and DOWN buttons to adjust intensity.

4. When “Single Color Amber” is displayed you are in Amber dimming

mode. Press the UP and DOWN buttons to adjust intensity.

5. You can use the color macro chart on page 16 to create one of the 35

macros.

DMX Mode:

Operating through a DMX controller gives the user the freedom to create

their own programs tailored to their own individual needs. The ELED TW

Strip has 8 DMX modes: 1 Channel mode, 2 Channel mode, 3 Channel

mode, 4 Channel mode, 6 Channel mode, 7 Channel mode, 27 Channel

mode, & 54 Channel mode. See pages 11-15 for each modes’ DMX

ELED TW Strip Operating Instructions
