©Elation Lighting® - www.elationlighting.com - ELED TRI PAR56 Instruction Manual Page 10©Elation Lighting® - www.elationlighting.com - ELED TRI PAR56 Instruction Manual Page 9

ELED TRI PAR56 Operating Instructions

DMX Mode:

Operating through a DMX controller gives the user the freedom to create

their own programs tailored to their own individual needs. This function

also allows you to use your fixtures as spot lights. The ELED TRI PAR56

has 6 DMX modes: 1 Channel mode, 2 Channel mode, 3 Channel mode,

4 Channel mode, 6 Channel mode, and a 7 Channel mode. See pages

10-12 for each modes’ DMX traits.

1. This function will allow you to control each individual fixture’s traits

with a standard DMX 512 controller such as the Elation® Show

Designer™ or the Elation® DMX Operator™.

2. To run your fixture in DMX mode, plug in the fixture via the XLR con-

nections to any standard DMX controller. Select your desired DMX

mode, and then press the UP or DOWN buttons to adjust the DMX

address.

3. To run the 1 Channel Mode, press the MODE button until “1000”

is displayed. This is the DMX addressing for the 1 Channel Mode.

4. To run the 2 Channel Mode, press the MODE button until “2000”

is displayed. This is the DMX addressing for the 2 Channel Mode.

5. To run the 3 Channel Mode, press the MODE button until “3000”

is displayed. This is the DMX addressing for the 3 Channel Mode.

6. To run the 4 Channel Mode, press the MODE button until “4000”

is displayed. This is the DMX addressing for the 4 Channel Mode.

7. To run the 6 Channel Mode, press the MODE button until “5000”

is displayed. This is the DMX addressing for the 6 Channel Mode.

8. To run the 7 Channel Mode, press the MODE button until “6000”

is displayed. This is the DMX addressing for the 7 Channel Mode.

9. Please see pages 10-12 for DMX values and traits.

ELED TRI PAR56 1 Channel - DMX Values & Functions

Channel Value Function

1 0 - 255 MACROS

ELED TRI PAR56 2 Channel - DMX Values & Functions

Channel Value Function

1 0 - 255 MACROS

2 0 - 255 DIMMER 0% - 100%

ELED TRI PAR56 3 Channel - DMX Values & Functions

Channel Value Function

1 0 - 255 RED

0% 100%

2 0 - 255 GREEN

0% 100%

3 0 - 255 BLUE

0% 100%

ELED TRI PAR56 4 Channel - DMX Values & Functions

Channel Value Function

1 0 - 255 RED

0% 100%

2 0 - 255 GREEN

0% 100%

3 0 - 255 BLUE

0% 100%

4 0 - 255 DIMMING

0% 100%
