Elation Professional - www.elationlighting.com - ELED QW Strip Instruction Manual Page 13
Elation Professional - www.elationlighting.com - ELED QW Strip Instruction Manual Page 14
Channel 1, 2, 3, & 4 will not work, when Channel 5 is being
used.
When using Channel 7, Channel 6 will control the speed of the
color changing.
ELED QW Strip 8 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 WHITE
0 - 255 0% - 100%
5 1 - 255 COLOR MACROS
PLEASE SEE COLOR MACRO CHART ON PAGE 17
6 STROBING/PROGRAM SPEED
0 - 15 NOTHING
16 - 255 STROBING
SLOW - FAST
1 - 255 PROGRAM SPEED SLOW - FAST
7 MODE
0 - 127 OFF
128 - 159 AUTO MIX
160 - 191 3 COLOR JUMP
192 - 223 7 COLOR JUMP
224 - 255 SOUND ACTIVE
8 MASTER DIMMER
0 - 255 0% - 100%
ELED QW Strip 36 Channel Mode
Channel Value Function
1 RED (LED 1 & 2)
0 - 255 0% - 100%
2 GREEN (LED 1 & 2)
0 - 255 0% - 100%
3 BLUE (LED 1 & 2)
0 - 255 0% - 100%
4 WHITE (LED 1 & 2)
0 - 255 0% - 100%
5 RED (LED 3 & 4)
0 - 255 0% - 100%
6 GREEN (LED 3 & 4)
0 - 255 0% - 100%
7 BLUE (LED 3 & 4)
0 - 255 0% - 100%
8 WHITE (LED 3 & 4)
0 - 255 0% - 100%
*CHANNELS 9-28 THE SAME RGBW LED PATTERN CONTINUES*
*THE DIRECTION IN WHICH THE PIXELS LIGHT UP CAN BE SWITCHED USING THE DIRECTION SET FEATURE ON PAGE 8*
29 RED (LED 15 & 16)
0 - 255 0% - 100%
30 GREEN (LED 15 & 16)
0 - 255 0% - 100%
31 BLUE (LED 15 & 16)
0 - 255 0% - 100%
32 WHITE (LED 15 & 16)
0 - 255 0% - 100%
33 RED (LED 17 & 18)
0 - 255 0% - 100%
34 GREEN (LED 17 & 18)
0 - 255 0% - 100%
35 BLUE (LED 17 & 18)
0 - 255 0% - 100%
36 WHITE (LED 17 & 18)
0 - 255 0% - 100%
