!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!31!!!!!!!!!!!!!!!!!!E!SPOT!LED!II™!User!Manual!1.0
12. EDIT MENU
This menu item allows you to write a program into the fixture’s internal memory
(EEPROM) via the control panel or via an external DMX controller. For more information on
using the built-in DMX controller see “Working with Built-In Programs” section page 36.
SEPR- Select program to be edit.
STEP (S-01 - S-48) - These are the Step slots (48 total) you write your programs into.
STXX (SC01 – SC48) - These are the Scenes (48 total) stored in your program.
C-01 - C-11 (Channel 1 - Channel 11) - Represents the total fixture channels for each
scene that can be edited.
TIME (Time) - Running time of the entire program.
CEDT - Edit program using a external controller.
REC – Auto save function.
RUN – Program test mode.
SEPR
Select a program to be edited.
STEP
Program the number of steps in your individual Program.
SC01
Set the total number of scenes in your internal Program.
RUN
Allows you to “RUN” the user-installed program. You can set the number of
steps under “STEP” (S-01- S-48), and you can edit the individual scenes under “EDIT”.
