Operation Guide
1. With the DM-2512R’s power switch OFF, connect data cables coming out of your lighting control devices
into the male, DMX Inputs, of the DM-2512R. Connect data cable to the output of DM-2512 and into first DMX
device in line.
2.
HTP
Backup
Merge
1 2
MODE
Set your desired function mode.
When signal is present to inputs A & B, DMX indicator’s should illuminate for both.
3.
4.
Turn the power switch ON. Indicator LED should illuminate.
Technical Specifications
Dimension:
Weight:
DMX Input:
DMX output:
Power Requirement: DC 9V, 1000mA Min.( AC/DC adaptor included)
(T )wo 3 pin XLR male sockets on the rear panel
(One )3 pin XLR female sockets on the rear panel
Two 3 pin XLR female sockets on the front panel
Two 3 pin XLR male sockets on the front panel
482 x 73 x 44mm
1.15 kg
