31!!!!!!!!!!DESIGN WASH LED ZOOM™ User Manual ver 1
DMX CHANNEL FUNCTIONS AND VALUES
ELATION© DESIGN WASH LED ZOOM™
DMX Channel Values / Functions (14 DMX Channels)
Specifications are subject to change without any prior written notice.
CHANNEL
VALUE
FUNCTION
1
PAN MOVEMENT [8 Bit]
0-255
PAN Movement
2
PAN MOVEMENT [16 Bit]
0-255
Fine Control Of PAN Movement
3
TILT MOVEMENT [8 Bit]
0-255
TILT Movement
4
TILT MOVEMENT [16 Bit]
0-255
Fine Control Of TILT Movement
5
SPEED PAN/TILT MOVEMENT
0-225
Max To Min Speed
226-235
Blackout By Movement
236-255
NO Function
6
RED LEDs [39 Total]
0-255
RED (0-Black - 255-100%)
7
GREEN LEDs [29 Total]
0-255
GREEN (0-Black - 255-100%)
8
BLUE LEDs [30 Total]
0-255
BLUE (0-Black - 255-100%)
9
WHITE LEDs [10 Total]
0-255
WHITE (0-Black - 255-100%)
10
SHUTTER, STROBE
0-31
Shutter CLOSED (ALL LEDs OFF)
32-63
Shutter OPEN (ALL LEDs ON)
64-95
Strobe Effect SLOW to FAST
96-127
Shutter OPEN (ALL LEDs ON)
128-159
Pulse Effect In Sequences
160-191
Shutter OPEN (ALL LEDs ON)
192-223
Random Strobe Effect SLOW to FAST
224-255
Shutter OPEN (ALL LEDs ON)
11
DIMMER INTENSITY
0-255
Intensity 0 to 100%
12
COLOR MACROS
0-7
NO Function
8-39
Color Macro 1
40-71
Color Macro 2
72-103
Color Macro 3
104-135
Color Macro 4
136-167
Color Macro 5
168-199
Color Macro 6
200-231
Color Macro 7
232-255
Color Crossfade SLOW To FAST
13
ZOOM
0-255
Zoom
