Design Wash LED Pro™
©Elation Professional, Los Angeles Ca. 10 www.ElationLighting.com
1. LED Assembly – 108 Philips Rebel LEDs comprise the LED assembly. 52 Red, 22
Green, 22 Blue, and 12 White.
2. Yoke Assembly – This assembly consist of the electronics and motors that control the
tilt movement as well as the LED operation.
3. Wireless Antenna – This antenna works with the built-in wireless DMX receiver. The
built-in wireless DMX system works with any Elation wireless system or any compatible
“EWDMX” system.
4. MENU Button - This button is used to access the menu functions.
5. Up Button – The up button is used to toggle forward through the menu functions and
settings.
6. Down Button – The down button is used to toggle backwards through the menu
functions and settings.
7. Enter Button – The enter button is used to enter in to a certain menu function or to lock
a function into memory.
8. LED Menu Display - 4-segment menu display. Used to display the DMX address as
well as all other menu functions.
9. Carrying Handle – Please use this intergraded handled to move the fixture form
location to location. Never carry the fixture by the head.
10. Cooling /Fan Assembly – The back of the head consist of the fan and cooling fin
assembly. To prevent the fixture from overheating, never block the back of the head
during normal operation.
11. 3-Pin DMX Output Jack – This jack is used to send an incoming DMX signal to the next
