Design Wash LED 60™
©Elation Professional, Los Angeles Ca. 7 www.ElationLighting.com
3. FEATURES
• Pan 540° or 630˚ (User selectable) / Tilt 265°
• 9˚ Beam Angle / 22˚ Field Angle
• 60 x 3-Watt SSC LED Light Source – (22 x Red, 17 x Green, 15 x Blue, 6 x White)
• 100,000 hours rated LED life
• Smooth additive RGBW color mixing, 16.7 million colors
• Flicker-free operation for television and film
• Low power consumption
• 3 operation mode: DMX controlled, stand alone or sound activated
• Strobe effect: 0~18 flashes per second or random strobe
• 0%~100% Dimming (two dimming options; linear & standard)
• Electronic menu display
• Control board with full LCD character display and foil-keyboard
• RDMX (Remote DMX addressing from any DMX console)
• Auto test for all functions
• Automatic Pan/Tilt Correction
• USITT DMX-512 Complaint (3-pin and 5-pin DMX Connections)
• Value of each DMX-channel can be displayed
• Minimal heat emission
• Maintenance free operation
• Preprogrammed colored macros
• Electronic power supply (100v~240V 50/60Hz)
• 7 built-in programs accessed via DMX-controller or manually
• Built-in DMX recorder - via the control board or external controller, up to 64 scenes
can be saved and then can be run in Stand Alone or sound activated.
