Design Wash 1400E™
©Elation Professional® 62 Design Wash 1400E™
23. TECHNICAL SPECIFICATIONS
Power supply
Power consumption
208 ~ 240V, 50/60 Hz
1800 Watt, 8.5 A, electronic ballast, (blind current compensated)
Fuse protection
220V = 10A/250V, GMA (5x20mm fine-wire fuse)
Lamp
Type
Philips Gold MSR 1200 FastFit
Life time
750 Hrs
Color temperature
6300˚ K
Luminous flux
95,000 lm
Optical system
Parabolic dichroic glass reflector
Lenses hardened and tempered, anti-reflex coated
Color Wheel
Color-wheel 1: 4 interchangeable dichroic glass colored filters plus "open"
Color-wheel 2: 2 interchangeable dichroic glass colored filters plus UV, CTB, & "open"
CMY Color mixing unit
Cyan color filter 0 - 100%
Magenta color filter 0 - 100%
Yellow color filter 0 - 100%
Shutter / Strobe / Dimmer
Strobe effect with variable speed 1 - 10 flashes per second
Continuously mechanical dimmer 0 - 100%
Focus
Motor driven focus from near to far away
Zoom
Zoom range 11° - 45°
DMX Channels
17 (16bit – default) or 15 (8bit – user selectable)
Drive
Standard DMX-512, 3 pole XLR; [+] = Pin 3 [-] = Pin 2 [Ground] = Pin 1 or 5 pole XLR; n/a = Pin
5, n/a = Pin 4, [+] = Pin 3, [-] = Pin 2, [Ground] = Pin 1
Starting DMX [001].
Pan / Tilt
Pan - movement
630° in max. 2.0 seconds, 16 bit resolution
Tilt - movement
265° in max. 1.5 seconds, 16 bit resolution
Weights and Measures
Width of the base
Length of the base
Width of Head
