Design Spot LED™
©Elation Professional® 19 Design Spot LED™
User Mode
Standard Mode
Basic Mode
Extended Mode
User Mode A
User Mode B
User Mode C
User’s mode to change
channel numbers
Users Mode Set
Edit User Mode
Max Channel = XX
PAN = CH01
:
Preset User modes
Select Programs
Auto Pro Part 1 = Program 1 ~ 10 Program 1
Auto Pro Part 2 = Program 1 ~ 10 Program 2
Auto Pro Part 3 = Program 1 ~ 10 Program 3
Select programs to be run
Edit Program
Program 1
:
Program 10
Program Test
Step 01=SCxxx
Step 64=SCxxx
Testing program
Program in loop
Save and exit
Edit Scenes
Edit Scene
001
~ Edit Scene
250
Pan,Tilt,……
--Fade Time--
--Scene Time--
Input By Outside
Save and automatically
return
manual scenes edit
Edit Program
Rec. Controller
XX~XX
Automat. scenes rec
7.1 Function Mode:
7.1.1 “Set DMX Address” - DMX address setting – This function is used to set or
adjust the fixture’s starting DMX address. Every device controlled by DMX has to have a
unique starting address. The addressing feature is what allows DMX to function
properly. The DMX address of a fixture is what allows it to communicate with a controller
properly. The DMX addressing also allows the fixture to ignore any DMX information
coming from the controller that is not meant specifically the fixture. Because each fixture
is connected in a daisy-chain fashion it is imperative to assign a proper and unique
starting DMX address to each and every fixture. The DMX address is non-destructive
and will remain in the fixture’s memory even when the power to the unit is switched off.
Memory is backed-up and retain by an internal power source that should last about five
years. For proper DMX addressing see Section 8/Page 29 of this user manual.
7.1.2 “Value Display” - Display the DMX 512 value of each channel
With this function you can display the DMX 512 value of each channel. The display will
automatically detail the changing DMX values as they are received from the controller.
