DESIGN LED 36WA™
©Elation Professional, Los Angeles Ca. 18 www.ElationLighting.com
8. OPERATING MODES
NOTE: The Design LED 36WA contains a total of 12 dipswitches. Only use
dipswitches 1~9 to set the DMX address. Dipswitches 10~12 are used for special
functions that are explained below.
Dipswitch 12: Mode Selection - When in the “OFF” position the fixture functions in
default mode, which is 3 DMX channels. When in the “ON” position the fixture
functions in 1 DMX channel mode.
Dipswitch 10 on & 11 off: Sound-active operation when used as a single stand-alone
unit or “master” unit.
Dipswitch 10 on and 11 on: Fixture functions as a “slave” unit in sound-active
operation.
Dipswitch 10 off and 11 on: Unit will function in manual mode, see chart below for
manual settings.
Working Mode
Dip
#11
Dip
#10
Dip
#9
Dip
#8
Dip
#7
Dip
#6
Dip
#5
Dip
#4
Dip
#3
Dip
#2
Dip
#1
NO function
OFF
OFF
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Sound Active –
Stand-Alone
ON
ON
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Sound Active –
Master Mode
OFF
ON
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Manual Mode –
Use Dipswitches
to set Intensity
ON
OFF
OFF
Use Dipswitches 1~8 to manual control the intensity. When
dipswitches 1~8 are all in the “on” position intensity will equal 100%
Preset Program
1
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ON
Preset Program
2
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
ON
OFF
Preset Program
3
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
ON
OFF
OFF
Preset Program
4
ON
OFF
ON
OFF
OFF
OFF
OFF
ON
OFF
OFF
OFF
Preset Program
5
ON
OFF
ON
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
Preset Program
6
ON
OFF
ON
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
Preset Program
7
ON
OFF
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
