DESIGN LED 36 Pro™
©Elation Professional, Los Angeles Ca. 10 www.ElationLighting.com
2. LED Display – 4-segment menu display. Used to display the DMX address as well
as all other menu functions.
3. Power Output Lead – This lead is used to jump power to another Design LED 36
Pro™. Please do not daisy-chain power for more than 16 fixtures.
4. DMX Out Lead – XLR female lead. This lead is used to send an incoming DMX
signal to the next fixture in the DMX chain.
5. Menu Button – This button is used to access the fixtures menu functions.
6. Up Button – The up button is used to toggle forward through the menu functions and
settings.
7. Down Button – The down button is used to toggle backwards through the menu
functions and settings.
8. Enter Button – The enter button is used to enter in to a certain menu function or to
lock a menu setting in to memory.
9. Yoke Assembly – This yoke is designed to perform two functions; 1) When split it
can be used as a floor stand bracket. 2) Used to secure a mounting clamp for truss
mounting.
10. Main Power Input Lead – This lead is the main power input lead.
11. DMX In Lead – XLR male lead. This lead is the main DMX input lead.
