DESIGN LED 36 BRICK™
©Elation Professional, Los Angeles Ca. 9 www.ElationLighting.com
in an array system.
6. Power Input/Fuse Holder Assembly – This assembly holds the safety fuse and
provides a female IEC connector for power. If needed, always replace fuse with an
exact match unless otherwise specified by an Elation Service Technician. Using a
fuse other than that specified could damage the unit and will void your warranty.
7. Eyebolt – Use this bold as a safety-cable rigging point. Always secure any
installation with a properly rated safety-cable.
8. Menu Button – This button is used to access the fixtures menu functions.
9. Up Button – The up button is used to toggle forward through the menu functions and
settings.
10. Down Button – The down button is used to toggle backwards through the menu
functions and settings.
11. Enter Button – The enter button is used to enter in to a certain menu function or to
lock a menu setting in to memory.
12. LED Display – 4-segment menu display. Used to display the DMX address as well
as all other menu functions.
13. 5-pin DMX In Jack – This jack accepts an incoming DMX signal via a male, 5-pin
XLR jack.
14. 5-pin DMX Out Jack – This jack is used to send an incoming DMX signal to the next
fixture in the DMX chain via a female, 5-pin XLR jack.
15. 3-pin DMX Out Jack – This jack is used to send an incoming DMX signal to the next
fixture in the DMX chain via a female, 3-pin XLR jack.
16. 3-Pin DMX In Jack – This jack accepts an incoming DMX signal via a male, 3-pin
XLR jack.
