DESIGN LED 12 BRICK™
©Elation Professional, Los Angeles Ca. 19 www.ElationLighting.com
8. OPERATING MODES
This fixture can run in three different DMX modes. The chart below describes how to access
the different DMX modes. The chart below also defines the how the channel will function in
the different DMX modes.
DMX
Operation
mode
DIP
#12
DIP
#11
LED control Mode
LEDs
control
channels
Preset
programs
channel
Strobe
channel
Master
dimming/
program
speed
15CH OFF OFF Each Led can be run
individually
1~12 13 14 15
12CH OFF ON Each Led can be run
individually
1~12
6CH ON OFF R, G, B run by group 1~3 4 5 6
Dipswitches 11 & 12: DMX Mode Selection, See the chart above; 15, 12, or 6 channel
modes.
Dipswitch 10: Sound-active operation when used as a single stand-alone unit or
“master” unit.
Manual Settings: The chart bellows details the dipswitch setting for various manual settings.
Refer to the chart on page 20 for specific static color settings and internal program access.
Operating
Mode:
Dip
# 11
Dip
#10
Dip
#9
Dip
#8
Dip
#7
Dip
#6
Dip
#5
Dip
#4
Dip
#3
Dip
#2
Dip
#1
No function
OFF OFF N/A N/A N/A N/A N/A N/A N/A N/A N/A
Sound
control-Stand
Alone
OFF ON N/A N/A N/A N/A N/A N/A N/A N/A N/A
Static R, G, B
(Refer to
Table 3)
ON OFF N/A N/A OFF Blue Blue Green Green Red Red
Preset
Program 1
ON OFF Speed Speed ON OFF OFF OFF OFF OFF ON
