8. OPERATING MODES

This fixture can run in three different DMX modes, the following pages will detail the different

operating modes as well as how to achieve the different operating modes.

DMX Settings: The chart below describes how to access the different DMX modes. The

chart below also defines the how the channel will function in the different DMX modes.

1． DMX Mode：

Form 1

DMX

Mode

LED Control model LED

channel

Internal

program

Strobe Dimmer/Speed

channel

Each control can be

controlled alone

1~12 13 14 15

channel

Each control can be

controlled alone

1~12 N/A N/A N/A

channel

Each color can be controlled 1~3 N/A N/A 4

channel

Each color can be controlled 1~3 N/A N/A N/A

Specification:

When in 15 channel mode, the reciprocal 3

, is the internal program channel, below the

value:

0---10 No function

11---40 Program 1

41---70 Program 2

71---100 Program 3

101---130 Program 4

131---160 Program 5

161---190 Program 6

191---220 Program 7

221---255 Program 8

When in 15 channel mode, the reciprocal 2

channel is the Strobe channel, below the

value:

0 Open

1----95 Strobe from slow to fast

96----127 Open

128---159 Pulse strobe from slow to fast

160---191 Open

192----223 Random strobe
