20 CUEPIX PANEL™ User Manual Ver. 3.2
ELATION© CUEPIX PANEL™
S Y S T E M M E N U - VERSION 3
Specifications are subject to change without any prior written notice.
MENU
OPTIONS / VALUES
DESCRIPTION
DMX MODE
ADDR:xxx
CH:xx
ADDR:001 - 512
CH:03, 04, 06, 07, 08, 75, 79, 80
DMX Address Setting
SECONDARY
M O D E
Set unit to Secondary Mode
AUTO RUN
FQN:xx
FQN:01-99
Set the number of times each internal macro will
repeat before moving to the next macro.
01.STATIC
-
15.FLOW 10
See INTERNAL MACRO MENU Select Internal Macro.
Dim Curve
Standard, Stage, TV, Architectural,
Theatre
Set desired Dimming Curve
Pixel Flip
STANDARD, Flip 1, Flip 2, Flip 3, Flip 4
Set starting Pixel (COB module).
See Pixel Flip Setting Section.
NO DMX MODE
Hold, Blackout, Program
Define how fixture reacts when NO DMX signal
present.
Manual RGB
R000-255 G000-255 B000-255 Set RGB Values manually for ALL 25 COB modules.
Ethernet
SetFixture ID
Service PINPassword=050 Enter Service Password to access Ethernet Menus.
Fixture ID
Device IP Addr
000.000.000.000
Set IP address.
(Need to enter Service PIN to access this menu)
Fixture ID
Ctrl Addr
000.000.000.000
Set Subnet Mask.
(Need to enter Service PIN to access this menu)
Fixture ID
Universe
000-255
Set DMX Universe number.
(Need to enter Service PIN to access this menu)
Ethernet Set
Protocol Set
Kling-Net, ArtNet Set Protocol.
Ethernet Set
Network Switch
ON, OFF Set Network switch.
