11 CUEPIX PANEL™ User Manual Ver. 3.2
INSTALLATION
FLAMMABLE MATERIAL WARNING
Keep fixture at least 5.0 ft.
(1.5m) away from any
flammable materials, decorations, pyrotechnics, etc.
ELECTRICAL CONNECTIONS
A qualified electrician should be used for all
electrical connections and/or installations.
CAUTIONS
For added protection, mount the fixture in areas outside walking paths, seating
areas, or in areas were unauthorized personnel might reach the fixture.
Ambient operating temperature range for this fixture is 5°F to 113°F (-15°C to 45°C).
Do not use the fixture under or above this temperature.
Before mounting the fixture to any surface, make sure the installation area can
hold a minimum point load of 10 times the weight of the fixture.
Fixture installation must always be secured with a secondary safety attachment,
such as an appropriate safety cable.
Never stand directly below the device when mounting, removing or servicing.
POWER LINKING
Max number of units that can be power linked is 2 units @120V and 4 units @220V.
CLAMP MOUNTING
The CUEPIX PANEL
™
provides an integrated yoke bracket. When mounting this fixture
to truss be sure to secure an appropriately rated clamps to the yoke/rigging bracket
using a M10 screw fitted through the center hole.
