www.elationlighting.com
10 CUEPIX BATTEN™ User Manual Ver. 1
FIXTURE INSTALLATION
FLAMMABLE MATERIAL WARNING
Keep fixture at least 5.0 ft. (1.5m) away from any
flammable materials, decorations, pyrotechnics, etc.
ELECTRICAL CONNECTIONS
A qualified electrician should be used for all
electrical connections and/or installations.
CAUTIONS
• For added protection, mount the fixture in areas outside walking paths, seating
areas, or in areas were unauthorized personnel might reach the fixture.
• Ambient operating temperature range for this fixture is 5°F to 113°F (-15°C to 45°C).
Do not use the fixture under or above this temperature.
• Before mounting the fixture to any surface, make sure the installation area can
hold a minimum point load of 10 times the weight of the fixture. (210 lbs / 950 kg)
• Fixture installation must always be secured with a secondary safety attachment,
such as an appropriate safety cable.
• Never stand directly below the device when mounting, removing or servicing.
POWER LINKING
Max number of units that can be power linked is 5 units @110V and 10 units @240V.
CLAMP MOUNTING
The CUEPIX BATTEN
™
provides an integrated yoke/rigging bracket. When mounting
this fixture to truss be sure to secure an appropriately rated clamps to the
yoke/rigging bracket using a M10 screw fitted through the center hole.
