17 ARENA PAR ZOOM™ User Manual ver 2
FIXTURE MENU
ON-BOARD SYSTEM MENU
The ARENA PAR ZOOM™ comes with an easy to navigate system menu. The next
section will detail the functions of each command in the system menu.
LCD MENU CONTROL PANEL
The control panel (see image below) located on back of the fixture allows you to
access the main menu and make all necessary adjustments to the ARENA PAR
ZOOM™. During normal operation, pressing MENU button once will access the
fixture’s main menu. Once in the main menu you can navigate through the different
functions and access the sub-menus with the UP and DOWN buttons. Once you
reach a field that requires adjusting, press the ENTER button to activate that field
and use the UP and DOWN buttons to adjust the field. Pressing the ENTER button
once more will confirm your setting. You may exit the main menu at any time
without making any adjustments by pressing and holding the MENU button for 3
seconds.
Some units may have the MENU control buttons silkscreened as pictured above
LEFT, and some units may have them as pictured above RIGHT. The control buttons
on both versions function in the exact same order: MENU, UP, DOWN, ENTER.
The MENU display will lock when NO buttons are pressed for 30 seconds. When the
display locks, none of the control panel buttons will respond. To unlock the display,
press and hold the MENU button 3 seconds to access the menu options once again
