6.4 DMX Channels
The AR-32 Architectural Recorder System has the ability to be controlled remotely using DMX512. The system
uses 3 DMX channels, with starting address configurable in the AR-32 Control System Software. Table 5
describes the DMX channel mappings.
Table 5
DMX Channel DMX Value Function
1 0-3 Trigger SHOW 1
4-7 Trigger SHOW 2
8-11 Trigger SHOW 3
12-15 Trigger SHOW 4
16-19 Trigger SHOW 5
20-23 Trigger SHOW 6
24-27 Trigger SHOW 7
28-31 Trigger SHOW 8
32-35 Trigger SHOW 9
36-39 Trigger SHOW 10
40-43 Trigger SHOW 11
44-47 Trigger SHOW 12
48-51 Trigger SHOW 13
52-55 Trigger SHOW 14
56-59 Trigger SHOW 15
60-63 Trigger SHOW 16
64-67 Trigger SHOW 17
68-71 Trigger SHOW 18
72-75 Trigger SHOW 19
76-79 Trigger SHOW 20
80-83 Trigger SHOW 21
84-87 Trigger SHOW 22
88-91 Trigger SHOW 23
92-95 Trigger SHOW 24
96-99 Trigger SHOW 25
100-103 Trigger SHOW 26
104-107 Trigger SHOW 27
108-111 Trigger SHOW 28
112-115 Trigger SHOW 29
116-119 Trigger SHOW 30
120-123 Trigger SHOW 31
124-127 Trigger SHOW 32
128-255 Close active show
2 0-79 PAUSE active show
80-160 PLAY active show
161-255 STOP active show
3 0-127 Normal output
128-255 BLACKOUT
