15 ACL CURTAIN™ User Manual Ver. 1
DMX CHANNEL FUNCTIONS AND VALUES
ELATION© ACL CURTAIN™
DMX Channel Values / Functions Version 1 (63 DMX Channels)
Specifications are subject to change without any prior written notice.
*Control of LEDs depends on the Pixel Flip setting.
DMX CHANNEL MODE VALUE FUNCTION
1CH:04 2CH:04 6CH 1CH:08 2CH:08 10CH 12CH 56CH 58CH 60CH 63CH 16 BIT CHANNELS
1 1 1 1 1 1
RED LED - All LEDS [1-14]
0-255
Red (0-Black - 255-100%)
2
RED LED FINE - All LEDS [1-14]
0-255
Red (0-Black - 255-100%)
2 2 2 3 2 2
GREEN LED - All LEDs [1-14]
0-255
Green (0-Black - 255-100%)
4
GREEN LED FINE - All LEDs [1-14]
0-255
Green (0-Black - 255-100%)
3 3 3 5 3 3
BLUE LED - All LEDs [1-14]
0-255
Blue (0-Black - 255-100%)
6
BLUE LED FINE - All LEDs [1-14]
0-255
Blue (0-Black - 255-100%)
4 4 4 7 4 4
WHITE LED - All LEDs [1-14]
0-255
White (0-Black - 255-100%)
8
WHITE LED FINE - All LEDs [1-14]
0-255
White (0-Black - 255-100%)
1 1 1 1
RED LED - LED [1]
0-255
Red (0-Black - 255-100%)
2 2 2 2
GREEN LED - LED [1]
0-255
Green (0-Black - 255-100%)
3 3 3 3
BLUE LED - LED [1]
0-255
Blue (0-Black - 255-100%)
4 4 4 4
WHITE LED - LED [1]
0-255
White (0-Black - 255-100%)
5 5 5 5
RED LED - LED [2]
0-255
Red (0-Black - 255-100%)
6 6 6 6
GREEN LED - LED [2]
0-255
Green (0-Black - 255-100%)
7 7 7 7
BLUE LED - LED [2]
0-255
Blue (0-Black - 255-100%)
8 8 8 8
WHITE LED - LED [2]
0-255
White (0-Black - 255-100%)
9 9 9 9
RED LED - LED [3]
0-255
Red (0-Black - 255-100%)
10 10 10 10
GREEN LED - LED [3]
0-255
Green (0-Black - 255-100%)
11 11 11 11
BLUE LED - LED [3]
0-255
Blue (0-Black - 255-100%)
12 12 12 12
WHITE LED - LED [3]
0-255
White (0-Black - 255-100%)
