13 ACL CURTAIN™ User Manual Ver. 1
ELATION© ACL CURTAIN™
S Y S T E M M E N U
Specifications are subject to change without any prior written notice. Defaults In Bold.
MENU
OPTIONS / VALUES
DESCRIPTION
DMX MODE
ADDR:001
CH:xx
ADDR:001 - 512
1CH:04, 2CH:04, CH:06, CH:08, CH:10,
CH:12, CH:28, CH:30, CH:32, CH:35
DMX Address Setting
DMX Channel Mode
SLAVE
M O D E
Set Fixture To Slave Mode
AUTO RUN
FQN:xx
FQN:01-99
Set Number Of Times Each INTERNAL PROGRAM MACRO
Repeats Before Moving To Next Macro.
01.STATIC
-
15.FLOW 10
01.STATIC
CL:RGB FADE00
Select INTERNAL PROGRAM MACRO.
Dim Curve
Standard, Stage, TV, Architectural,
Theatre
Set Desired Dimming Curve
Pixel Flip
OFF, ON
Set Starting Pixel LED.
See Pixel Flip Setting Section.
NO DMX MOD
Hold, Blackout, Program
Define How Fixture Reacts When NO DMX Signal Present.
Manual
R000-255 G000-255 B000-255
W000-255 Strobe:000
Set RGBW + Strobe values manually for ALL 7 LEDs.
Macros
00-64
Set Color Macro.
Fan Set
Fan Speed
Auto, High, Low
Set Fan Speed
LCD Set
Blacklight 02S-60S [05S]
LCD Display Shutoff Time.
Key Lock [OFF]
Set Control Display Key Lock Feature.
DispFlash [ON]
LCD Display flashes when NO Signal is detected.
Temp
F° , C°
Set temperature to F° / C°
DFSE
OFF, ON Restore Factory Settings.
Info
Time.Info
Current: 0000H
Total Time: 0000H
Last Clear: 0000H
Timer PIN: XXX
Clear Last [OFF, ON]
Displays Internal Timers.
Enter PIN=066 To Access Clear Last Function.
Temp. Info
XXX F°
Displays Current Fixture Temperature.
Model. Info
ACL Curtain
Displays Model Name.
Software
1U:01 ≥V1.12
2U:01 ≥V1.09
Displays Software Versions. (Greater Than or Equal To)
Ethernet Set
Fixture ID
Service PIN: XXX
Enter PIN=050 to access Network Menus.
Fixture ID
Device IP Addr
000.000.000.000
Set Fixture IP Address.
(Need to enter Service PIN to access this menu)
Universe 000-255
Set DMX Universe number.
(Need to enter Service PIN to access this menu)
Protocol Set
ArtNet, Kling-Net
Set Protocol.
Network Switch
ON, OFF
Set Ethernet switch.
