22 ACL 360 BAR™ User Manual
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
11
13
37
DIMMER INTENSITY
0-255
Intensity 0 to 100%
12
14
38
DIMMER INTENSITY FINE
0-255
Dimmer Intensity FINE Adjustment
13
15
39
AUTO PROGRAM MACROS
0
NO FUNCTION
1-20
01 - Single LED Chase Sequence #1
21-40
02 - Center LED ON then Burst LEDs Out Towards Both Ends and Back
41-60
03 - Single LED Chase Sequence #2
61-80
04 - Single LED Chase in Alternating Directions Sequence
81-100
05 - Single to ALL LED Fill Chase in Same Direction Sequence
101-120
06 - All LEDs ON Color Changing Sequence
121-140
07 - Outside to Inside back to Outside LEDs Chase / Color Sequence
141-160
08 - Single LED Chase Sequence Yellow/Green Color
161-180
09 - Single LED Chase Sequence Light Purple Color
181-200
10 - Single LED Chase Sequence Light Blue Color
201-220
11 - Outside to Inside back to Outside LEDs Chase Sequence Yellow/Green Color
221-240
12 - Outside to Inside back to Outside LEDs Chase Sequence Light Purple Color
241-250
13 - Outside to Inside back to Outside LEDs Chase Sequence Light Blue Color
251-255
14 - All LEDs ON Color Gradient Sequence
14
16
40
AUTO PROGRAM MACRO SPEED
0-255
Auto Program Macro Speed SLOW to FAST
15
17
41
DIMMING CURVE MODES
0-20
STANDARD
21-40
STAGE
41-60
TV
61-80
ARCHITECTURAL
81-100
THEATRE
101-255
Default to Unit Setting
16
18
42
PAN / TILT MOVEMENT SPEED
0-225
MAX to MIN SPEED
226-235
Blackout By Movement
236-255
NO FUNCTION
17
19
43
LAMP ON/OFF, RESET, INTERNAL PROGRAMS
0-79
Normal
80-84
ALL Motor Reset
85-99
NO FUNCTION
100-119
Internal Program 1 (scene1~8 of EEPROM)
120-139
Internal Program 2 (scene9~16 of EEPROM)
140-159
Internal Program 3 (scene17~24 of EEPROM)
160-179
Internal Program 4 (scene25~32 of EEPROM)
180-199
Internal Program 5 (scene33~40 of EEPROM)
200-219
Internal Program 6 (scene41~48 of EEPROM)
220-239
Internal Program 7 (scene49~56 of EEPROM)
240-255
NO FUNCTION
