18 ACL 360 BAR™ User Manual
DMX CHANNEL FUNCTIONS AND VALUES
ELATION© ACL 360 BAR™
DMX Channel Values / Functions Version 1 (43 DMX Channels)
Supports Software Versions: ≥1.28
Specifications are subject to change without any prior written notice.
*Pixel control position depends on the specific Pan/Tilt position of the head.
MODE / CHANNEL
VALUE
FUNCTION
BASIC
STAND
EXTEND
1
1
1
PAN MOVEMENT [8 BIT]
0-255
PAN Movement 630/540
2
2
PAN FINE MOVEMENT [16 BIT]
0-255
Fine Control of PAN Movement
2
3
3
TILT MOVEMENT [8 BIT]
0-255
TILT Movement
4
4
TILT MOVEMENT [16 BIT]
0-255
Fine Control of TILT Movement
3
5
5
PAN CONTINUOUS MOVEMENT
0-127
NO FUNCTION
128-189
PAN Clockwise from FAST to SLOW
190-193
NO Rotation
194-255
PAN Counter-Clockwise from SLOW to FAST
4
6
6
TILT CONTINUOUS MOVEMENT
0-127
NO FUNCTION
128-189
TILT Clockwise from FAST to SLOW
190-193
NO Rotation
194-255
TILT Counter-Clockwise from SLOW to FAST
5
7
RED (ALL LEDs)
0-255
0 to 100%
6
8
GREEN (ALL LEDs)
0-255
0 to 100%
7
9
BLUE (ALL LEDs)
0-255
0 to 100%
8
10
WHITE (ALL LEDs)
0-255
BLUE FINE Adjustment
7
*RED - LED 1
0-255
0 to 100%
8
*GREEN - LED 1
0-255
0 to 100%
9
*BLUE - LED 1
0-255
0 to 100%
10
*WHITE - LED 1
0-255
0 to 100%
11
*RED - LED 2
0-255
0 to 100%
12
*GREEN - LED 2
0-255
0 to 100%
13
*BLUE - LED 2
0-255
0 to 100%
14
*WHITE - LED 2
0-255
0 to 100%
