www.elationlighting.com 18
Station Mode DHCP Enable
Turn DHCP on or off when running in station mode.
When DHCP is enabled, the network router will assign an IP address to the 4Cast DMX Bridge.
This is convenient on a large network where available IP addresses may not be known.
When DHCP is off, a specific static IP address must be entered, which is described in the next
section. When running the 4Cast DMX Bridge in sACN mode IP addresses can be set by the
network router using DHCP, as this protocol doesn’t need IP addresses to send messages.
!
When making this setting change, a system reset is required.
DHCP Assigned IP Address [added in software version V-3E]
This will let you view the IP address that is assigned by a router when DHCP is enabled in
station mode. This is for information only; no changes are possible from the bridge.
Station Mode Static IP Address
Enter a static IP address if 4Cast DMX Bridge is running in station mode and DHCP is
disabled. The 4Cast DMX Bridge uses IPV4 style addresses. The 4Cast DMX Bridge will try
to join a network using this IP address. Care must be taken to match the IP address to the
network’s address settings. The default address 192.168.0.150 will most likely work (NOT
guaranteed) if the network router is located at address 192.168.0.1 as is most common. If
using more than one 4Cast DMX Bridge device on a network, set each bridge to a different
address by incrementing the last number, for example 150, 151, etc. for each consecutive
4Cast DMX Bridge on the network. DHCP can be used if IP Addressing is unfamiliar.
!
When making this setting change, a system reset is required.
STA'IP'address' '
192.168.000.150'
STA'DHCP'enable' '
enabled'
STA'DHCP'enable' '
off'
DHCP'assigned'IP' '
192.168.0.11'
