USE OF REMOTE CONTROL
1. First open the battery cover at the back of the remote control, and install a
(CR2032 3V) battery.
How to open the battery cover: first press and hold in the direction of arrow 1 in
the figure to release the upper snap of the battery cover, and then pull it out in the
direction of arrow 2.
2. When using, please align the position of the receiver.
3. When the power of the battery is exhausted, pull out the battery cover according
to the direction shown in the figure, and replace with a new battery (CR2032 3V).
When replacing the battery, please pay attention to the polarity, and then reset the
battery cover.
Information requirements related to ecodesign
Description Symbol Value Unit
Maximum fan ow rate F 33,85 m
3
/min
Fan power input P 28,10 W
Service value SV 1,21
(m
3
/min)/
W
Standby power consumption PSB 0,78 W
Fan sound power level LWA 63,16 dB(A)
Maximun air velocity c 3,55 m/sec
Measurement standard for service value EN IEC 60879:2019
Contact details for obtaining more
information
El Corte Inglés S.A.
Hermosilla, 112 - 28009 Madrid · España
CLEANING AND MAINTENANCE:
WARNING: ALWAYS UNPLUG THE UNIT BEFORE MOVING OR SERVICING. DO NOT
IMMERSE THE POWER CORD, PLUG AND THE WHOLE APPLIANCE INTO WATER
OR RINSE UNDER THE TAP!
Caution: Do not use detergent, gasoline, benzene, thinner, or other solvents to clean
the unit to avoid damage of the appliance.
-
Unplug the unit and wait until the fan stop running before cleaning.
-
Use a damp cloth to clean the surface of the fan.
