Specifications
37
ES100E
Height, working maximum
472.4 Inch
Height, platform maximum
393.7 Inch
Height, stowed maximum
Railing raised
96.8 Inch
Height, stowed maximum
Railing lowered
72.4 Inch
Width with standard wheels
45.3 Inch
Length, stowed
94.5 Inch
Length, platform extended
133.86 Inch
Platform dimensions (length
x width)
90.1 x 45.3
Inch
Platform extension length
39.4 Inch
Maximum load capacity
704 Lbs
Maximum wind speed
12.5 m/s
Wheelbase
72.8 Inch
Turning radius (outside)
86.6 Inch
Turning radius (inside)
0m
Ground clearance
3.7 Inch
Ground clearance
Pothole guards deployed
0.78 Inch
Weight
6204 Lbs
(Machine weights vary with option
configurations. See serial label for specific
machine weight.)
Power source
4Batterys 6V 180Ah
(Lithium battery 25.6V 220Ah)
System voltage
24V
Controls
Proportional
AC outlet in platform
Standard
Maximum hydraulic
pressure (functions)
240Bar
Tire size
Φ381×129
Sound pressure level
<70 dB
The maximum noise level normally (A level
detection)
Total vibration value is subjected does not
exceed 2.5 m/s
2
Maximum slope rating,
stowed position
25%
Maximum side slope rating,
stowed position
25%
Note: Slope rating is subject to ground
conditions.
Maximum working slope
3°/1.5°
Drive speed
Stowed, maximum
3.5km/h
Platform raised, maximum
0.8km/h
Floor loading information
Tire load maximum
2618 Lbs
Tire contact pressure
1213kPa
Occupied floor pressure
11.68kPa
Note: Floor loading information is approximate
and does not incorporate different option
configurations. It should be used only with
adequate safety factors.
