Operating Instructions
28
Operational Indicator Codes
Operator, machine and fixed objects should
keep a safe distance. Pay attention to the
direction when using the controller.
Battery level indicator
Full Low
LED diagnostic reading devices used to
determine the battery level.
How to Use the Safety Arm
1. Raise the platform approximately 3 m
from the ground.
2. Rotate the safety arm away from the
machine and let it hang down.
3. Lower the platform until the safety arm
rests securely on the link. Keep clear of
the safety arm when lowering the
platform.
There will be no load when
using the safety arm.
How to Fold Down the Guardrails
The platform railing system consists of a fold
down rail section for the extension deck and
one section for the main deck. All sections are
held in place by four wire lock pins.
1. Fully lower the platform and retract the
platform extension.
2. Remove the platform controls.
3. From inside the platform, remove the two
extension deck lock pins.
4. From the middle of the extension deck
railing, fold down the extension deck rail
assembly toward the rear of the unit.
5. Replace the two removed pins back into
each side of bracket.
6. At the rear of the main deck, remove the
two main deck lock pinsć
7. Fold down the rear gate and entry side
rails as one unit. Keep hands clear of
pinch points.
8. Replace the two removed pins back into
each side of bracket.
9. Fold down right extended platform
guardrail, keep hands free of pinch
points.
10. Fold down the main right guardrails form
the step or the ground. Keep hands free
of pinch points.
11. Fold down left extended platform
guardrail, keep hands free of pinch
points.
12. Fold down the main left guardrails form
the step or the ground. Keep hands free
of pinch points.
13. Replace the two removed pins back into
each side of bracket.
How to raise the guardrails
Follow the folding instructions, but in reverse
order, ensuring all lock pins are in place and
installed properly.
Extension and indented
platform
1. Foot the footplate on the extended
platform.
2. Push the extended guardrails and extend
the position you want.
Do not stand on the extended platform when
you try to extend the platform.
