Figure 2 Technical Parameters
Table 2 Main technical parameters of the standard version
Character
istics
Model
ER15L
ER15
Power
electric
electric
Operator type
Seated-on
Seated-on
Load capacity
Q (lb)
3300
3300
Load center
c (in)
24
24
Wheelbase
y (in)
53.94
53.94
Weights
Service weight(include
battery)weight(include
battery)（含电瓶）
lb
4555
4800
Wheels/T
ires
Wheels type
PU
PU
Driving wheel size
Φ×w(in)
Φ9.8×2.9
Φ9.8×2.9
Bearing wheel size
Φ×w(in)
Φ5.9×3.2
Φ5.9×3.2
Balance wheel size
Φ×w(in)
Φ5.8×2.3
Φ5.8×2.3
Wheels, number
from/rear(x=driven)
1
，
4/2
1
，
4/2
Front wheelbase
b10 (in)
24.4
24.4
Rear wheelbase
b11 (in)
38.7
38.7
Dimensio
ns
Mast tilt Forward/backward
α/β (°)
3/5
3/5
Lowered mast height
h1 (in)
90.5
86.6
Free lift height
h2 (in)
0
53
Lift height
h3(in)
138
177
Extended mast height
h4 (in)
174
215.7
Lower fork height
h13 (in)
1.6
1.6
Overall length
l1 (in)
94
（
45.3
）
94
（
45.3
）
Body length
l2 (in)
64.96
64.96
Overall width
b1/ b2(in)
45.3
45.3
Fork size
s/e/l (in)
1.4/3.9/45.3
1.4/3.9/45.3
Outer side fork width
b5 (in)
7.9-25.59
7.9-25.59
Reach distance
l4(in)
19.7
19.7
Ground clearance ,centre of
wheelbase
m2 (in)
2.2
2.2
Aisle width for pallets
1000*1200 crossways
Ast (in)
106.3
106.3
Aisle width for pallets
800*1200 lengthways
Ast (in)
108.7
108.7
Turning radius
Wa (in)
62.8
62.8
Performa
nce
Travel speed,
Laden/unladen
(km/h)
5.2/5.5
5.2/5.5
