14
(such as caused by others),turn off the car power and remove the key when not
operating
5.Test run, Transportation, Outage
5.1Test run
Table 3 test data
Model
EB16EAS
EB16EA
Packing weight（lbs.）
3680
3542
Lifting height（Inch）
216.54
216.54
Size（Inch）
80*47.8*98.036
81.65*47.8*98.03
After receiving our new forklift or when it needs to be retest please with process with
following steps before (the first )operation of the forklift :
• Check if all parts are included .and there is no damage
• Battery installation and charging (refer to Chapter 9)
• Carry out daily inspection and machine function inspection
5.2Lifting & Transportation
Remove the cargo during transportation ,Lowered the
fork to the lowest position And according to Figure 5 Safety
fixed the car with special lifting equipment
Lifting
Use Special Crane and lifting equipment
Don’t stand under shaking cargo
Don’t enter the dangerous area when rising
Parking the truck safely，and bind the truck as figure 5 Shows
Lifting the truck to the destination ,Before Moving lifting
equipment please safety Fixed the car ,
The rope point can refer to figure 6
Transportation
The Truck should be firmly fixed on the truck during transportation
Lowered fork and parking the truck safety
As figure 6 shows Use the special binding belt to fix the tow big ribs of the car .And fixed
other side on the carrier
5.3Outage
When Storage remove the cargo and lowered the fork to lowest position. Grease all
lubrication points mentioned in this manual (check regularly)to prevent rust and dust.
！
Fig 5 Lifting Point
Fig6 Fixed Point
