11
Main technical parameter list
Mode
EB16EA
EB16EA+C(With side
shifter
Drive type
Electric
Electric
Type of operation
Walkie type
Walkie type
Load Capacity
Q (LBS)
4400
4400
Load center
x (Inch)
23.62
23.62
Distance between fork
backrest and front wheel
c (Inch)
32.08
30.59
Wheelbase
y (Inch)
63.78
63.78
Service Weight
（
with
battery
）
Q (LBS)
3542
3680
Tire material
PU
PU
Driving wheel size
Φ×w(Inch
)
Ö9.84×2.95
Ö9.84×2.95
Bearing wheel size
Φ×w(Inch
)
Ö3.15×2.76
Ö3.15×2.76
Balance wheel size
Ö×w(Inch
)
Ö4.53×2.17
Ö4.53×2.17
No of Driving wheel, Balance
wheel/Bearing
wheel(X=Driving wheel
1x+2/4
1x+2/4
Front wheelbase
b
10
(Inch)
22.83
22.83
Rear wheelbase
b
11
(Inch)
42.91-56.69
42.91-56.69
Lowered mast height
h1 (Inch)
98.03
98.03
Free lift height
h2 (Inch)
64.57
61.25
Lift height
h3 (Inch)
216.54
216.54
Extended mast height
h4 (Inch)
251.18
253.54
The height of handle in the
operation position
h
14
(Inch)
39.76/57.08
39.76/57.08
Lowered fork height
h
13
(Inch)
2.36
2.17
Overall Length
l
1
(Inch)
81.65
80
Body Length
l2 (Inch)
36.37
37.87
Overall Width
b
1
/ b
2
(Inch)
47.8-61.58/31.81
47.8-61.58/31.81
Fork Size
s/e/l
(Inch)
1.58/4.72/45.28
1.58/4.72/45.27
Fork Width
b5 (Inch)
9.84-31.5
15.2-24.65
Ground clearance under mast
m
2
(Inch)
1.02
1.02
Aisle width for pallets
1000*1200 crossways
Ast (Inch)
101.77-107.87
102.76
Turing Radius
Wa (Inch)
69.57
69.57
Driving Speed
，
load/unload
(km/h)
5.2/5.5
5.2/5.5
Lifting Speed load/unload
(mm/s)
95/160
95/160
Lowered Speed load/unload
(mm/s)
130/110
130/110
Maximum gradeability
load/unload
(%)
5 /.8
5 /.8
Brake Type
Electromagnetic
brake
Electromagnetic
brake
Driving Motor
(kW)
3
3
Lift Motor
(kW)
3
3
Battery
，
according to DIN
43531/35/36 A,B,C,no
no
no
Battery voltage/rate capacity
(V/Ah)
24/210
24/210
Battery Weight
（
±5%
）
(LBS)
462
462
Type of drive control
AC
AC
Noise level
(dB(A))
70
70
