6. Parts List
No.
Code
Name
Specificatio
n
Quantity
1
GB/T 818-2000
Cross recess pan head screw
M6×20
14
2
EA10.0-6
Guard clamp
6
3
EA1016.0-4
Protective cover
1
4
EA10.9-2
Electrical cover
1
5
GB/T 96.2-2002
Large (big) plain washer
φ6
6
6
GB 2674-86
Socket button head screws
M10×25
2
7
EA10.4-3
Cover
2
8
GB/T 276-94
Deep groove ball bearing
6205
8
9
GB/T 297-94
Tapered roller bearing
30205
2
10
GB/T 97.1-2002
Plain washer
φ24
3
11
EA10.6.1
Wheel frame welded parts of
driven pulley
1
12
EA10.4.1
Steering handle
1
13
EA10.4-1
Pin roll
1
14
GB 894.1-86
External circlip
φ10
4
15
GB 894.1-86
External circlip
φ12
3
16
EA 10.4-2
Connecting shaft
1
17
EA10.4-6
Spacer bush
2
18
EA10.4-7
Gas spring
1
19
EA10.4-4
Gas spring shaft
1
20
EA10.5-7
The push rod screw
1
21
GB_T 2084-94
Cylindroid helical-coil
compression spring
1
22
EA10.5-4
Skate brake
1
23
EA10.5-8
CAM pedal
1
24
EA10.5-3
Pin roll
1
25
GB/T 70.1-2000
Hexagon socket cap screws
M12×100
2
26
EA10.5.2
Nylon wheel
2
27
EA10.5-1
Bushing
2
28
GB/T 276-94
Deep groove ball bearing
6204
10
29
EA10.5-2
Axle sleeve
4
30
GB/T 93-1987
Spring washer
φ12
2
31
GB/T 6170-2000
Hex nut
M12
2
32
EA10.5.1
The brake wheel frame
welded pieces
1
33
ISO08A
Chain
2
34
EA10.5-5
Shaft filler washer
2
35
EA10.4-8
Steering chain
2
36
GB/T 1096-2003
General flat key
6×8
1
37
EA10.4.2B
The handle base
1
38
EA10.4-5
Steering shaft.
1
39
EA10.4.3-1,4
Draw-in bolt
4
40
GB/T 41-2000
Hex nut
M10
9
41
EA10.4.3-2
Strainer
2
42
GB/T 6176-2000
Hex nut
M18×1.5
1
43
GB/T 93-1987
Spring washer
φ10
7
