Je bekijkt pagina 8 van 9
- 7 -
44
GB/T 95-2002
Flat washer
φ10
5
45
CMB1-VB1303060-
120
pump station
1
46
TY-01.36
Emergency Stop Switch
1
47
TY-01.42
SPN charging plug
1
48
GB/T 818-2000
cross recess pan head screw
M4×20
4
49
GB 923-88
acorn nut
M10
1
50
GB 923-88
acorn nut
M8
2
51
GB/T 41-2000
Hex nut
M8
2
52
GB/T 93-1987
Spring washer
φ8
2
53
GB/T 95-2002
Flat washer
φ8
2
54
EA10.16.1
The door frame component
1
55
GB/T 5781-2000
Hex bolt thread
M10×55
1
56
EA10.0-2
Oil cylinder hoop
1
57
EA10.8-6
Fuel pipe union
1
58
GB/T 70.1-2000
Hexagon socket cap screws
M10×25
2
59
GB/T 97.1-2002
Flat washer
φ10
2
60
TY-01.43
Coulombmeter
1
61
EA 10.9.1
Distribution box
1
62
12V120Ah
Battery
1
63
EA10.8-2T
Block cover
1
64
EA10.8-3
Bushing
1
65
EA10.8-4
Oil cylinder
1
66
GB/T3683-92
High-pressure oil pipe
1
67
ISO12A
Chain
2
68
EA10.0-1
Chain pull rod
2
69
GB/T 6170-2000
Hex nut
M14
4
70
GB/T 93-1987
Spring washer
φ14
2
71
EA10.2.2-3
Footstock
1
72
GB/T 70.1-2000
Hexagon socket cap screws
M8×16
1
73
EA10.2-5(G)
Chain wheel
2
74
GB 894.1-86
Circlip for shaft
φ20
6
75
GB 893.1-86
Circlip for hole
φ47
2
76
EA 10.8-1
Piston rod
1
77
12V20A
Charger
1
78
EA10.8-5
Piston rod
1
79
EA10.8-9
Detent ring
1
80
EA10.0-1
Front wheel
2
81
EA10.0-3
Small shaft
2
82
EA10.3.1
Fork frame welded
1
83
EA10.3.2-2
Adjust baffle plate
2
84
EA10.3.2
Fork
2
85
EA10.3-2
Major axis
1
86
GB 894.2-86
Circlip for shaft
φ32
2
87
GB/T 77-2000
Hexagon socket set screw
with flat point
M12×20
4
88
EA10.3-1
Pallet rack roller
4
89
GB 894.2-86
Circlip for shaft
φ25
4
90
GB 893.2-86
Circlip for hole
φ52
4
91
EA10.3-3
Lateral pressure pad
4
