34
Chapter 7 Reference
7-4. Preset Timing
The following table shows factory preset analog signal timing.
Attention
• Display position may be deviated depending on the PC connected, which may require screen adjustment using
Setting menu.
• If a signal other than those listed in the table is input, adjust the screen using the Setting menu. However, screen
display may still be incorrect even after the adjustment.
• When interlace signals are used, the screen cannot be displayed correctly even after screen adjustment using the
Setting menu.
Resolution
Applicable
Signals
Frequency Polarity
Dot Clock:
MHz
Horizontal:
kHz
Vertical: Hz Horizontal Vertical
640 × 480 VGA 25.18 31.47 59.94 Negative Negative
640 × 480 VESA 31.50 37.86 72.81 Negative Negative
640 × 480 VESA 31.50 37.50 75.00 Negative Negative
720 × 400 VGA TEXT 28.32 31.47 70.09 Negative Positive
800 × 600 VESA 36.00 35.16 56.25 Positive Positive
800 × 600 VESA 40.00 37.88 60.32 Positive Positive
800 × 600 VESA 50.00 48.08 72.19 Positive Positive
800 × 600 VESA 49.50 46.88 75.00 Positive Positive
1024 × 768 VESA 65.00 48.36 60.00 Negative Negative
1024 × 768 VESA 75.00 56.48 70.07 Negative Negative
1024 × 768 VESA 78.75 60.02 75.03 Positive Positive
1280 × 720 CEA-861 74.25 45.00 60.00 Positive Positive
1280 × 960 VESA 108.00 60.00 60.00 Positive Positive
1280 × 1024 VESA 108.00 63.98 60.02 Positive Positive
1280 × 1024 VESA 135.00 79.98 75.03 Positive Positive
1680 × 1050 VESA CVT 146.25 65.29 59.95 Negative Positive
1680 × 1050 VESA CVT RB 119.00 64.67 59.88 Positive Negative
1920 × 1080 CEA-861 148.50 67.50 60.00 Positive Positive
