GB
- 13 -
Fitting the handle (Fig. 4)
Use a screwdriver to fi t the handle (1) using both
screws (21).
5.2 Fitting the fi lters
Notice!
Never use the wet and dry vacuum cleaner wit-
hout a fi lter.
Always ensure that the fi lters are securely seated.
Fitting the foam fi lter (Fig. 7)
For wet vacuuming, slip the supplied foam fi lter
(16) over the fi lter basket (Fig. 2/4). The pleated
fi lter (15) already fi tted upon delivery is not suita-
ble for wet vacuuming.
Fitting the pleated fi lter (Fig. 8)
For dry-vacuuming, slip the pleated fi lter (Fig. 15)
over the fi lter basket (Fig. 2/4). The pleated fi lter
(15) is suitable for dry-vacuuming only.
Fitting the dirt bag (Fig. 8a)
For vacuuming fi ne, dry dirt it is recommended
that you also fi t the dirt bag. This will ensure that
the pleated fi lter (15) does not clog up so quickly
and help maintain the vacuuming power. It also
makes it easier to dispose of the dust. Slip the
dirt bag over the vacuuming hole. The dirt bag is
suitable for dry-vacuuming only.
5.3 Fitting the suction hose (Fig. 9-12)
Connect the suction hose (11) to the correspon-
ding connector on the wet and dry vacuum clea-
ner, depending on the application required.
Vacuuming
Connect the suction hose (11) to the suction hose
connector (9).
Blowing
Connect the suction hose (11) to the blow con-
nector (10).
To extend the suction hose (11) you can attach
one or more of the elements which make up the
2-part suction tube (12) to the suction hose (11).
5.4 Suction nozzles
Combination nozzle (13)
The dual-purpose nozzle (13) is for vacuuming
solids and liquids over medium to large areas.
Crevice nozzle (Fig. 11)
The crevice nozzle (23) is designed for vacu-
uming solids and liquids in corners, edges and
other areas that are diffi cult to access.
6. Operation
6.1 ON/OFF switch (Fig. 2/2)
Switch position 0: Off
Switch position I: Normal mode
6.2 Dry vacuuming
For dry-vacuuming, use the pleated fi lter (15). In
addition, you can also fi t the dirt bag. (See point
5.2)
Always ensure that the fi lters are securely seated.
6.3 Wet vacuuming
For wet-vacuuming, use the foam fi lter (16) (see
point 5.2).
Check that the fi lter is securely seated at all times.
Water drain screw (Fig. 1)
To make the tank (8) easier to empty after wet va-
cuuming, it is fi tted with a water drain screw (19).
Open the water drain screw (19) by turning it anti-
clockwise and drain the liquid.
When wet vacuuming, the fl oating safety switch
(5) closes when the maximum tank level is
reached. At the same time, the suction noise of
the equipment will change and become louder.
You must then switch off the equipment and em-
pty the tank.
Danger!
The wet and dry vacuum cleaner is not suitable
for the vacuuming of combustible liquids. For wet
vacuuming, use only the supplied foam fi lter.
6.4 Blowing
Connect the suction hose (11) to the blow con-
nector (10) on the wet and dry vacuum cleaner.
7. Replacing the power cable
Danger!
If the power cable for this equipment is damaged,
it must be replaced by the manufacturer or its
after-sales service or similarly trained personnel
to avoid danger.
