19
Adjustment of the sliding pieces:
Warranty
According to the general supply conditions for business dealings, suppliers have to
provide to companies a warranty period of 12 months for redhibitory defects. (to be
documented by invoice or delivery note)
Damage due to natural wear, overstressing or improper handling are excluded
from this warranty.
Damages due to material defects or production faults shall be eliminated free of
charge by either repair or replacement.
Complaints will be accepted only if the tool is returned in non-dismantled condition
to the manufacturer or an authorized Eibenstock service centre.
EU - Declaration of conformity
It is necessary that the machine (f. e. PLD 450 B) used in this drill rig comply with
the requirements which are described in the specifications of the drill rig (f. e.
drilling diameter, fixture of the motor).
We declare that this unit has been designed in compliance with 2006/42/EC.
This unit must not be put into service until it was established that the Power Tool to
be connected to this unit is in compliance with 2006/42/EC (identified by the CE-
marking on the Power Tool).
Vakuum Technik GmbH Eibenstock
Lothar Lässig
24.04.2024
A
A
Loosen the counter nut on the Allen screw (A) by
means of an jaw wrench SW 13
Adjust the Allen screws and the position of the
thrust piece to the column by means of a hex
head wrench SW 6.
Tighten the counter nut again and check whether
the carriage moves easily on the column.
