14
Care and Maintenance
Always keep the drill rig clean, especially the column with the toothing and
the 4 sliding pieces in the machine holder.
In order to allow the free movement of the pinion shaft, it should be slightly
lubricated.
In order to achieve a good performance of the drill rig, the 4 sliding pieces
in the machine holder have to move along the column without slackness.
Attention:
After every tenth drilling you should check if the sliding pieces have got
loose-fitting due to drilling vibration.
If the position should have changed, it can be readjusted as follows:
Loosen the counter nut on the Allen screw by
means of an jaw wrench
SW 17
Adjust the Allen screws and the position of the
thrust piece to the column by means of a hex
head wrench SW 8.
Tighten the counter nut again and check whether
the carriage moves easily on the column.
Behavior at Malfunction
Turn off the machine at malfunction and disconnect from the
main supply. Operations on the electrical system of the
machine can be executed by a specialist only.
Trouble Shooting
malfunction
possible cause
repair
Drill unit has to
much play
(vibration)
stand has been loose
guidance has to much play
thrust piece worn
adjust the wing nut
adjust guidance (see above)
replace the thrust piece
