12
Technical characteristics
Measures: 1320x1320x1590 mm
Drilling heights: 250 – 1300 mm
Weight: 27,9 kg
Fixture of the motor: Neck clamping Ø 60mm
Order no. 09655000
Available special accessories:
Item
Order no.
Column extension EBW 1300 3582G000
Reducing ring Ø 60 – Ø 53 mm 35820000
Reducing ring Ø 60 – Ø 43 mm 35821000
Supply
Drill stand Bohrwurm EBW 1300 with operating instructions in the carton.
Application for indented purpose
The Bohrwurm EBW 1300 is a mobile stand for core hole drilling. Differing from
freehand drilling, the Bohrwurm significantly reduces the risk of injuries (for
example to the wrist). It can be used with diamond core drills, drilling machines
and hammers with mounting via clamping neck Ø 60mm (e.g.: ETN 162/3) or
smaller, with use of bushings, for horizontal drilling.
In case of wrong handling or misuse, the producer does not assume any
liability.
Safety Instructions
Safe use of the tool is only possible if the user had
studied the instruction manual and safety instructions
completely and is strictly following the instructions
contained therein. Additionally, the general safety
instructions of the leaflet supplied with the tool must be
observed. Prior to the first use, the user should absolve a
practical training.
Perform a visual inspection before each use of the Bohrwurm. At this time,
pay attention to the following: Cracks, leakage, damaged, loose, or missing
parts.
In case of any damage, the Bohrwurm no longer may be used and must be
repaired by a qualified repair service.
