15
Technical Data
Percussion Diamond Core Drill ESD 162
Nominal voltage 230 V ~
Power drain 2200 W
Rated current 10,0 A
Frequency: 50/60 Hz
No-
Load speed:
0-1100 rpm
Percussion frequency:
max. 22000/min
Bit holder: 1 ¼“ UNC - R½¨ i
Max. drilling diameter concrete: 82-162 mm (brickwork up to 202mm)
Protection class: I
Degree of protection: IP 20
Weight: approx. 6.7 kg
Order No. 03E25000
Interference suppression acc.to: EN 55014 and EN 61000
Available add-ons:
Item Order No.
Diamond drill rig BST 162H 0963W000
Fastening set concrete/stone 35720000
Diamond drill bit dry Ø 82, 102, 132 and 162mm
Copper ring for easier drill bit removal 35450000
Wet/dry deduster ESS 35 MP 09931000
For further information about our products and our wide range of
accessories please see: www.eibenstock.com.
Supply
Diamond core drill with 2 open-end wrench (SW32 and SW41) and
instruction manual in transport case.
Application for Indented Purpose
The diamond core drill ESD 162 is indented only for professional use and
may be used only by instructed personnel.
With an appropriate drill bit, the tool can be used for drilling of concrete,
stone, bricks, sand-lime bricks and pore concrete.
For drilling jobs with diameters above 132mm (102mm in reinforced
concrete) it is a must to use a suitable drill rig.
The machine may be used exclusively in conjunction with a vacuum
cleaner of dust category M.
Concrete and reinforced concrete are to be drilled only with soft impact.
The user alone is liable for damage caused by improper use.
