Thesideatwhichthedooropenscanbe

changed,fromtherightside(assupplied)

totheleftside,iftrequired.

Warning!Whenreversingthedoor,the

appliancemustnotbeconnectedtothe

mains.Ensurethattheplugisremoved

fromthemainssocket.

Toolsyouwillneed

LeftHingeCover

8mmwrench

8mmsocketwrench

Monkeywrench

Thin-blade

screwdriver

Cross-shaped

screwdriver

2.Useaputtyknifeorthin-blade

screwdrivertoprizethescrewholecover

whichisatthetopleftcornerofthe

refrigerator,andtheupperhingecover

whichisatthetoprightcornerofthe

refrigerator.

Reversingthedoor

Note:Ifrequiredyoumaylaythe

refrigeratoron its back inorder togain

access tothebase you should rest it

on soft foampackaging or similar

material toavoiddamaging the

backboard of therefrigerator. To reverse

the door thefollowing steps

,

, are

generallyrecommended

1.Stand the refrigerator upright Open

theupper door to take out all door

racks(toavoiddamage) and then close

thedoor

.

.

.

Puttyknife

3.Unscrewthespecialflangeself-tapping

screwswhichareusedforfixingtheright

upperhingepartbya8mmsocketdriver

oraspanner(pleasesupporttheupper

doorwithyourhandwhendoingit).

rightupperhingepart

specialflange

selftappingscrews

4.Removetheupperhingeaxis,transferit

toreversedsideandtightensecurely,then

putitinasafeplace.

①

② ③

5. Remove the upper door from the

middle hinge by carefully lifting the door

straightup.

When removing the door, watch

for washer(s) between the center hinge

and the bottom of the freezer door that

maysticktothedoor.Donotlose.

NOTE:

Reversingthedoor

9

upperhinge

cover(right)

screwholecover

Doorracks
