15
6. TECHNICAL DATA
USER/INSTALLER
6.1. Technical data according to the product standard BENCH 54 INT
The data shown is indicative and obtained during the certification phase at a notified body according to current
regulations.
Quantity
BENCH 54 INT
Rated power
Output power
9,4
kW
Yield
85,4
%
CO emissions at 13% O
2
0,050
%
Smoke temperature
232
°C
Fuel consumption
2,4
kg
Draught
12,1
Pa
Minimum volume of installation room
47
m
3
Heatable volume
245
m
3
Smoke duct diameter
150
mm
Air intake duct diameter
80
mm
Weight with packaging
158
kg
Energy efficiency class (Regulation 1185/2015)
A+
Environmental Class according to the Italian
Ministerial Decree 186
5 stars
Minimum distance of combustible materials from
Back/Side/Front
200/200/1300
mm
Minimum distance of combustible materials from
Ceiling/Floor
NPD: (No declared
performance)
mm
NOTES ON THE TECHNICAL DATA
To calculate consumption, a heating value of 4.6 kW/Kg was used.
The heatable volume is calculated considering a heat demand of 33 Kcal/m³ per hour.
The product can work safety also with a higher draught. However, an excessive draught may result in switch-off
and/or decreased efficiency.
