11
Installing the Door Handles
To install the door handles:
1. Open the left door and carefully pull the door gasket around the area where the handle
is to be installed.
2. Carefully remove the two pre-installed decorative plugs from the front of the door.
3. Insert each Phillips head screw through the gasket side of the door until the screw
passes through the door.
4. Align the handle with the screws and tighten using a Phillips head screwdriver until the
handle is ush against the door frame.
5. Carefully press the door gasket into its original position.
6. Repeat steps 1 through 5 for the right door handle.
Note: Some refrigerators do not have decorative plugs installed.
Warning: Do not over-tighten the screws as this may cause damage to the handle or the
stainless steel door.
!
Installing the Wine Shelves
To prevent damaging the door gasket, make sure to open the door fully before pulling the shelves o
their tracks.
1. Open the left zone door completely.
2. Identify the protective stoppers located on the right and left sides of the back of each wooden
wine shelf.
3. Lift either the left or right side of the shelf creating a 45° angle.
4. Insert the shelf at the desired track level and push back
slowly until it stops in place.
5. Gently set the shelf down in place; it should be level.
Removing the Wine Shelves
1. Open the left zone door completely.
2. Make sure the shelf is pushed back completely (towards
the rear wall).
3. If necessary, make sure you remove all the contents
sitting on the shelf.
4. Identify the protective stoppers located on the right and left sides of the back of each wooden
wine shelf.
5. Lift either the left or right side of the shelf creating a 45° angle from its original position. Make
sure not to lift either side of the shelf too hard as it may come in contact with the inner wall mount.
6. Pull the shelf forward until it is completely removed from the inner compartment. Set aside safely.
