10.1.3 WiLD-SB18
WiLD-SB18
WiS (RF Wireless Digital Audio)
Frequency band
1880 - 1930MHz,EU DECT, US DECT
Coverage range
Up to 150m from a TX to any paired RX, direct line of sight
Audio channels
1 stereo audio ch received from the WiLD-TX network
Audio transmission
16 bit uncompressed, 48kHz SR
Digital Audio Sample size
16bit
Digital Audio Sampling rate
48kHz
Digital Audio Frequency Response
10Hz – 15kHz (-1dB)
Digital Audio converters
ADC Resolution: 24 bits
Dynamic range
ADC: 96 dB
Latency
From TX Analog Audio IN to RX Speaker <26ms
Pairing time
Up to 60s
System
Effective Freq. Range
1
57Hz-693Hz (-10dB)
Sensitivity
2
92 dB (1W/1m)
Maximum SPL
3
112 dB continuous / 118 dB peak
Transducers
Ways
1-way full range
Driver
8" woofer
Nominal impedance
4Ω
Powered
Power
100W RMS / 150W peak
Audio inputs
Wireless Audio: Digital, Mono
Line in: ST unbalanced 3-pin Euroblock
Audio outputs
Internal Loudspeaker: Analog, Mono, Self powered
THD + Noise
<1% @1Hz Full power
Signal Noise Ratio
>110dB @100W RMS
Input sensitivity
-8dBV / 10kΩ (wireless Audio)
-15 dBV / 10kΩ (line in)
Electrical
Power supply
Universal, internal power supply
AC mains requirement
100-240VAC @ 50-60Hz
AC mains connector
standard 2-pin AC plug
Power consumption
150W
Power consumption standby
＜
2W
Ventilation
Convection cooled
Monitoring and Control
Volume control
Led display, +/- volume buttons
Other controls
PAIR: via WiLD button
LP Filter: via volume buttons
StandBy: via volume buttons
LED Indicators
Status
Auto standby time
20min, 1H, 2H, 4H, On
Auto standby threshold
>50 dB
Physical
Installation options
Floor, Wall-mount brackets
Enclosure material
MDF
Mounting system
Metal brackets
