10. TECHNICAL DATA
10.1 Technical Specifications
10.1.1 WiLD-TX
WiLD-TX
WiS (RF Wireless Digital Audio)
Frequency band
1880 - 1930MHz,EU DECT, US DECT
Coverage range
Up to 150m from a TX to any paired RX, direct line of sight
Audio channels
1 stereo audio ch received from the WiLD-TX network
Audio transmission
16 bit uncompressed, 48kHz SR
Digital Audio Sample size
16bit
Digital Audio Sampling rate
48kHz
Digital Audio Frequency Response
10Hz – 15kHz (-1dB)
Digital Audio converters
ADC Resolution: 24 bits
Dynamic range
ADC: 96 dB
Latency
From TX Analog Audio IN to RX Speaker <26ms
Analogue Audio Inputs
Number of inputs
1
Connection type
2 xRCA unbalanced
Input sensitivity
-10dBV to 0dBV
Input impedance
>20kΩ
Max input level
+6.021dBV
THD + Noise
<1% (1kHz)
Bluetooth Audio Input
Class
Compliant 5.3, Class 2&3
Range
25m (ideal conditions)
Profiles
A2DP1.3.2/AVRCP1.6.2
Supported codecs
SBC
Control Connectivity
USB
Power supply and Service & firmware updates
Analogue remote control
Compatible with WPa series analogue volume control
panels
External MUTE
Normally Open
Electrical
Power supply
External, universal Power Supply
AC mains requirement
100-240 VAC @ 50-60Hz, using supplied DC adapter
AC mains connector
5VDC IN mains USB-C
Power consumption
1A at 5V
Monitoring and Control
Paring control
Back panel button
Source selection
Front panel switch
Volume control
Front panel knob
Tone control
Front panel knob
MUTE control
GPI
LED Indicators
Status
Auto standby time
1200 seg
Auto standby threshold
20 dB
