5
IMPORTANT NOTE
Thank you for choosing our Ecler VEO-XWT44E HDbaseT wallplate transmitter.
It is VERY IMPORTANT to carefully read this manual and to fully understand its
contents before any connection in order to maximize your use and get the best
performance from this equipment.
To ensure optimal operation of this device, we strongly recommend that its maintenance
be carried out by our authorised Technical Services.
All ECLER products are covered by warranty, please refer to www.ecler.com or the
warranty card included with this product for the period of validity and conditions.
INTRODUCTION
Ecler VEO-XWT44 is a HDbaseT transmitter in European 2-gang wallplate format. It
allows to extend one 4K video signal up to 40m over a single Cat 5e/6 cable or a FullHD
signal up to 70m when connected to VEO-XRT44. It supports real 4K video signals at
60Hz with 4:4:4 YUV chroma subsampling and HDR 10 with a maximum bandwidth of
18Gbps. With bidirectional PoC feature, the transmitter can be powered by the receiver
and vice versa. VEO-XWT44 includes 2 HDMI 2.0 Inputs and one USB-C Input selectable
via front panel button, automatic switching feature or RS-232. It allows extending IR and
a bidirectional RS-232 signal along with the video signal. A second front panel button
can be used to switch ON/OFF a display via CEC or it can be alternatively programmed
by IR learning or RS-232 to send two RS-232 commands, offering a simple and versatile
control option.
Features:
⚫ 4K HDMI wall-plate transmitter with 2 HDMI IN, and 1 USB-C IN
⚫ Supports HDMI 2.0, 4Kx2K/60Hz/4:4:4
⚫ HDCP 2.2 compliant
⚫ Video source auto-switching
⚫ Video lossless compression for HDBaseT technology, transmission up to 40m@4K
and 70m@1080p over CATx cable
⚫ Displays can be turned ON/OFF via CEC & RS-232 commands by ‘DISPLAY
ON/OFF’ button
⚫ RS-232 and IR pass through.
⚫ IR learning to control display on/off.
⚫ EDID pass through and smart managing
⚫ Two-way PoC
⚫ Supports CEC pass-through.
