7. TECHNICAL DATA
7.1 Technical Specifications
VEO-XPT412
Video Performances
Video Input Connectors
Transmitter: 1 x HDMI
Type A Female, 2.0, 18Gbps;
1 x RJ-45 Female , HDBaseT 1.0
Video Output connectors
Receiver: 1 x HDMI
Type A Female, 2.0, 18Gbps;
1 x RJ-45 Female , HDBaseT 1.0
Video Input Resolutions
480i, 480p, 720i, 720p, 1080i, 1080p up to 60Hz, 1920 x
1200/60Hz, 4K up to 60Hz
Video Output Resolutions
480i, 480p, 720i, 720p, 1080i, 1080p up to 60Hz, 1920 x
1200/60Hz, 4K up to 60Hz (with Colour Space Conversion
Technology)
Chroma Subsampling
4:4:4
，
4:2:2
，
4:2:0
Colour Depth
8-bit (4K 60Hz 4:4:4) , 10-bit / 12-bit (4K 60Hz 4:2:2 – 4:2:0)
Colour Space
RGB, YCbCr, YUV
HDCP
2.2, 1.4
HDR
HDR10, HDR 10+, Dolby Vision
，
HLG
HDMI
Distance
Up to 4K/60Hz: 5m with IN/OUT HDMI
Cable
Up to 1080p/60Hz: 10m with IN/OUT HDMI
Cable
Audio Performances
Audio Output Connectors
3-pin Euroblock
Audio Formats
LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby
Digital Plus(DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X
Sample Rate
48KHz, 96KHz, 192KHz
Bit Depth
Up to 24-bit
Frequency Response
20Hz-20KHz (±3dB)
Device Control
EDID Management
Pass-through
Status Indicators
Power LED, HDBaseT status LED's
Pass-Through Control
Pass-through Connectors
1 x 3-pin Euroblock, 1 x Jack 3,5mm, 1 x HDMI
Pass-through Protocols
RS-232, IR, CEC
HDBaseT Specification
HDBaseT Version
HDBaseT 1.0
Transmission Distance
4K/60Hz up to 120m with Cat 5e or higher
1080p/60Hz up to 150m with Cat 5e or higher
Electrical
Power Supply
PoH; External: Input 100-240VAC @ 50/60Hz 0.6A, Output
24VDC-1A
AC Mains Connector
External PSU. Included 4 region power blades (UK,US,AU,EU)
DC Mains Connector
DC Locking
Power Consumption
9.36W
Physical
Operating Temperature
Min: 0°C; 32°F
Max: 40°C; 104°F
Operating Humidity
20% to 90% HR, non-condensing
Storage temperature
Min: -20°C ; -4°F
Max: 60°C ; 140°F
