5.2 Video Switching Control
The signal switch includes 8 free switching channels, which can be configured as input/output
according to the requirements, forming a matrix of 1 x 8 ~ 8 x 1, which can switch any input
signal to a single output or simultaneously to all outputs.
• To switch input channel to the output, select the "output channel" + "input channel",
follow these steps:
1. Press the desired input channel selection.
2. Press the desired output channel that you want to associate with the selected "input
channel".
• To assign an input channel all output channels, follow these steps:
1. Long press any input channel for 2 seconds.
Examples:
• Switch input 1 to output 4
Operation: press input1 and then output4 to complete switch
• Switch input 4 to all outputs
Operation: long press input 4 to complete the switch.
• All output switch to input 4
Operation: long press any output and then long press input 4 to complete switch.
If time between pressings exceeds 10s, it will be necessary to press output button again.
