5.8 Remote Controlling
VEO-MXH88D can be remotely controlled over RS-232 or TCP/UDP communications
protocol.
• For RS-232 serial communication: enter the selected parameters on
Series Port Setting
chapter.
• For TCP/UDP communication: enter the current VEO-MXH88D IP address and Port:
5000 for TCP or 5001 for UDP commands.
5.8.1 Series Port Setting
The serial parameters for a correct transmission are:
Baud rate 115200 (by Default) | Data bits 8 | Stop bits 1 | Parity None | Flow
control None
For a correct communication, both the host PC and VEO-MXH88D need to have the
same baud rate amongst the available options.
5.8.2 Command List
• All commands start with “#”
• “_” the underline cannot be omitted.
• Command head, Parameter and target need to add one “SPACE”.
Command Code
Description
Command Return
#video_d input=[x] output=[y]
Switches Video Input channel [x] to Output
channel [y]
PARAMETERS DESCRIPTION
• [x]: Input channel number, ranging from 1
to 8. If [y]= output channel number
•
[y]= 0, all outputs
<Output[x] : Video source> [Data=[y-1] : Input [y]]
#video_d output= [x] onoff=[y]
Turns on and off Output channel [x]
PARAMETERS DESCRIPTION
• [x]: Output channel number, ranging from
1 to 8. If [x]=0, all output
• [y]:
ON = 1
OFF = 0
<Output[x] : Video OnOff> [Data=[y-1] : Input [y]]
video_d input=[x] onoff=[y]
Enable or disable input channel [x]
PARAMETERS DESCRIPTION
• [x]: Input channel number, ranging from 1
to 8. If [x]=0, all output
• [y]:
ON = 1
OFF = 0
<Input[x] : Video OnOff> [Data=[y-1] : onoff [y]]
