8. TECHNICAL DATA
8.1 Technical Specification
8.1.1 PULSO-4
PULSO-4
PI
Processor
Quad-Core ARM, up to 1.8GHz
SCREEN/DISPLAY
Size
4"
Resolution
480 x 480 pixels
Contrast Ratio
800:1
Brightness
350 cdm2
Scale
1:1
Display
4'' IPS Active area 71.86(W)x70.18(H)mm
Backlight
LED
Touch-panel
5 points capactive touch panel
MONITORING AND CONTROL
Buttons
Reboot and Factory Reset micro buttons
CONNECTIVITY
Ethernet
1 RJ-45 connector, cable: Cat-5e or better
10 /100Mb, 1GB Auto X-Over
Supports PoE
Serial port
RS-232, Euroblock connector
Programing and control
Embedded application. Compatible with Ecler prodcuts
ENM, EPX, VIDA, HALO, HUB.
ELECTRICAL
Power supply
DC 12V 2A & PoE
PoE
Class 0 802.3af Poe PD compliant
Max power consumption
6W
PHYSICAL
Type
Control touch panel
Format
Standard EU single-gang compatible
Installation options
In-wall and desktop (with optional accessory) mount
Operating temperature
Min: -10°C ; 14°F
Max: 60°C ; 140°F
Operating humidity
≤75%
Storage temperature
Min: -20°C ;-4°F
Max: 70°C ; 158°F
Storage humidity
≤75%
Included accessories
Security screw
Optional accessories
Pulso Desktop Mount (under development)
Dimensions (WxHxD)
89.34 x 89.34 x 37 mm / 3.52 x 3.52 x 1.46 in.
Weight
0.15 Kg / 0.33 lb
Shipping dimensions (WxHxD)
145 x 80 x 130 mm / 5.71 x 3.15 x 5.12 in
Shipping weight
0.37 Kg / 0.82 lb
